功能与介简/Brief Introduction：

机器是所代替口服药方式液安全钢化可瓶子子的新车辆，恢复克服了往昔口服药方式液安全钢化可瓶子子的无良使用效果。此灌封机用到的可瓶子，显然不必须要 洗瓶机、烘干设备机，更不必须要 酒精消毒，可直接性灌封。机械全智能理瓶、进瓶、罐装生产线，罐装生产线量不稳，无漏滴，无瓶不罐装生产线。上盖、封膜率led光通量100%。此机工艺最新，容积小、正常运行不稳、燥声低，方法维护、家电清洗简单等特征 ，完成适用GMP规格。This machine is a new product instead of oral liquid bottles, thoroughly solved before the adverse effect of oral liquid glass bottle. The used plastic bottles, filling and sealing machine not only don't need to bottle washer, dryer, more don't need disinfection, can be directly potting. The machine is fully automatic unscramble bottle, bottle feeding, filling, filling volume stability, no LouDi, no bottle no filling. Cover and sealing rate can reach 100%. This machine technology is advanced, small volume, stable running, low noise, convenient operation and maintenance, cleaning, etc, in full compliance with GMP standard.注：本技术参数有中速和髙速两种类型出产量供您抉择。Note: this model has two kinds of low speed and high-speed production for your choice.

共同点 Characteristic

◆机器可使用在于各个易折瓶胶囊液测量分装和粘口。The machine is suitable for all kinds of folding bottles of oral liquid filling and sealing of measurement.◆任何电热器元器件均所采用知名品店牌著名大品牌。All electrical components adopt famous brand◆超声波焊接机操作方法直接便捷，无瓶不灌装线，记量*。It has intuitive and convenient operation, no bottle no filling, measuring precision.◆易折塑料制品瓶灌封机的具体结构类型与原则Easy to fold the main structure and principle of plastic bottle filling and sealing machine◆NFGFY型口服药液易折橡胶瓶灌封机主要的理瓶器、理盖器、主传动系统设计系统软件、同部带齿隙送罐系统设计、玻璃瓶子检漏系统设计、灌装线组织 、排除系统设计、热溶封组织 、汽动机器手指头夹瓶组织 、交流伺服直流无刷电机直流无刷电机齿隙上瓶组织 与出瓶组织 等组合。Type NFGFY oral liquid is easy to fold the plastic bottle filling and sealing machine main GaiQi bottle opener, and the main transmission system, the synchronous belt clearance to send bottle device, empty bottle leak detection device, filling body, eliminating device, hot melt sealing mechanism, pneumatic mechanical fingers bottle gap on the bottle structure, servo motor and a bottle of institutions, etc.◆器机在使用的服食液易折朔胶瓶、盖也是定无尘区生孩子的，应当药袋材准许证，因此瓶身与底盖经引入和"去外包公司"后可可以直接流入灌封间。凭借理盖器、理瓶器的自动化定向分配就业收纳整理，删去反方向底盖及瓶身底口朝下的瓶，使定向分配就业后的包材喂料有规律地流入输送带导轨中。Machine using oral liquid is easy to fold the plastic bottles, cover a certain production of clean area, should have the medicine packaging material license, so the bottle and the bottom cover after transfer and "outsourcing" can go directly into the potting. By Richard GaiQi, automatic directional arrangement of bottle opener, eliminate reverse bottom cover and the bottom of the bottle mouth bottle at the bottom, after making the orientation of packaging material feeding regularly into orbit. ◆定向就业后补血口服液液易折朔胶瓶在卸料轨道组件第二排Directional oral liquid after folding plastic bottles in conveying rail out easily

的技术规格technical parameters：

型号model	NLGFY-40	NLGFY-80
装量范围内The load range	5-100ML
生产能力production capacity	20-40瓶/分	50-80瓶/分
密封率Hot sealing intensity	》99%
装量差值The load error	《1.5%
耐磨损率damage rate	《1.0%
输出功率power	2KW	3KW
电源开关Power Supply	380V 50Hz/220V 50Hz
外形尺寸boundary dimension	2700*1100*1900mm	3000*1480*1900mm
质量 Weight	700Kg	800Kg
