主要用途与简单介绍/Brief Introduction：

这手机采取特有三通接头装灌阀，适宜于水剂和膏霜类新产品的装灌，尤为对高粘稠度原料（如浓酱、干辣椒酱、番茄酱、种衣剂、微乳剂、飘浮剂等）的目的对比明星，且精确高。这手机采取PLC可代码编程调节，搭配6厘米手触屏人机对战软件界面系統，推行自功进瓶，自功装灌，自功出瓶，电气，液压元配件均采取知名品脾，有效确保安全生产了优秀的质量管理和长久稳定性高的特点。本机 架构十分简单，运行简单方便，是我们国家很理想的造成高粘稠度原料的装灌机 。这手机有了杜绝漏滴与拔丝的装灌闷头，有效确保安全生产装灌完后后无漏滴，无拔丝。Filling valve, the machine USES special tee is suitable for the filling agent and cream products, especially for high viscosity material (such as thick sauce, chili sauce, tomato sauce, indicated, micro emulsion, suspending agent, etc.) of the effect is obvious, and high precision. The machine USES PLC programmable control, with 6 inch touch screen man-machine interface system, implements the automatic into the bottle, automatic filling, automatic bottle, electric, pneumatic components adopt international brand, to ensure that the performance of the outstanding quality and lasting stability. This equipment has simple structure, convenient operation, is the ideal filling equipment for high viscosity material. The machine is equipped with prevent drip with wire filling cocks, ensure filling after the completion of a drip-tight, no drawing.

特质/Characteristic：

◆调整平台性——按照西门子PLC调整平台性，分装使用量随意稍微调一下。Control system adopt mitsubishi PLC control system, filling dose random tweaks◆进行操作方法用户工具栏——6屏幕尺寸彩屏手触式进行操作方法用户工具栏，主观简洁明了、安全性高可信度Interface - 6 inches color hand touch interface operation, intuitive and simple, safe and reliable◆特点键改进什么——排料有防漏滴装制，可据原物料特点具有下潜装罐特点键。（此特点键就可以运用）Improvements - blanking drip tight device, according to the material properties have diving filling function. (this function can be chosen)◆电子产品器件——均进行时代国际有名气名牌，抓实机械的安全卫生靠谱、最准确高朝；Electrical components adopt international famous brand, to ensure the equipment safe and reliable, high accuracy;◆机械厂元件——电脑元件均进行特色304不绣钢质作,烦请必须要 相处废料可以进行316L另记账用。Mechanical parts, machine parts are made of high quality 304 stainless steel material can be used if necessary contact 316 l in extra costs.◆运算查测——立即运算，对任务产品的生产数量举例子反映出。Counting test, real-time, intuitive reflect the yield of work.◆装灌检验——无瓶不灌、瓶数不足不灌Bottle filling test - no bottle no filling, not enough◆养护保养情况下——机器适用GMP需求，可更快拆装、刷洗养护保养。Maintenance - the machine is in line with the GMP requirements, easy disassembly, cleaning maintenance.◆变换要求参数——变更灌装线要求参数时，只需要简单化修正，高效追到。Changing specifications - change the filling specifications, simply adjust, easy fix.◆节能节能标准配值——配值了节能节能标准前端框架，使机械的运行节能进一步的清洁节能。（此节能节能标准配值不错选装）Environmental protection configuration, configuration framework of environmental protection, make the operation of the machine environment more clean sanitation. (the environmental protection configuration can be selected)

水平主要参数/technical parameters：

灌装设备头数The number of filling head	8头（先选4、6、8、10、11个装灌头）8 head (opti𝓰onal 4, 6, 8, 10, 12 filling head)
适用于瓶径 Applicable bottles Drive	Ф33-Ф100 mm
量值溯源计算精度measure precision	±1%
罐装数量Canned capacity	150-1000ml
分娩水平Production Capacity	2400-4000瓶/一小时2400-4000   bottles per hour
气源压力bleed pressure	0.7-0.9mpa
电    源Power Supply	380 伏/50 HZ
总 功 率The total power	0.5 kw
外形尺寸 boundary dimension	6000×850×1800 mm
重    量Weight	500kg
